Clinical-Pathological Conference Series from the Medical University of Graz

A panel of diagnostic tests was performed.

In this hypertensive patient, hyperaldosteronism (primary aldosteronism) should also be considered. Primary aldosteronism is defined as inappropriately high and (relatively or absolutely) autonomous aldosterone secretion, which is not adequately suppressed by sodium loading [1]. The clinical features of primary aldosteronism are caused by hypersecretion of aldosterone and increased activation of the mineralocorticoid receptor (MR) in the distal nephron. Importantly, the MR is additionally expressed in a variety of epithelial and non-epithelial extrarenal tissues, such as endothelial cells, vascular smooth muscle cells, cardiac myocytes, endothelial progenitor cells and neutrophils [2]. Both (1) the increased aldosterone-MR mediated renal effects (leading to moderate sodium and water retention and excessive potassium excretion) and (2) aldosterone-MR and direct aldosterone mediated (MR-independent and non-genomic) vascular effects (contributing to e.g. vascular stiffening and endothelial dysfunction) result in arterial hypertension and, variably, hypokalemia [3‐5]. Only 9–37 % of patients with primary aldosteronism present with hypokalemia, so that it is not essential for diagnosing aldosterone excess [6]. In severe cases of primary aldosteronism, hypokalemia may be expressed as muscle weakness, particularly in the lower extremities, muscle spasms, palpitations and, rarely, hypokalemic paralysis [7], which might indeed be responsible for our patient’s tetraparesis.

Primary aldosteronism is the most common curable form of arterial hypertension and is reported in approximately 5–10 % of hypertensive patients and in approximately 20 % of those with documented treatment-resistant hypertension [8, 9]. Our patient is young and has a medical history of hypertension obviously resistant to antihypertensive drugs, both of which are important diagnostic clues for primary aldosteronism. In primary aldosteronism, younger hypertensive patients often respond poorly to angiotensin-converting enzyme inhibitors, angiotensin receptor blockers, calcium channel blockers and beta-blockers [10]. The use of different drugs, as in the discussed case, suggests primary aldosteronism.

Due to increased renal loss of H⁺ ions, alkalosis is often observed in primary aldosteronism and hypokalemia followed by secondary hyperparathyroidism due to the hypercalciuric effects of aldosterone is also a common feature of the disease. Unfortunately, the protocol does not include any data on the patient’s acid-base balance and serum calcium levels.

Taken together, severe hypokalemia and hypokalemic paralysis in a young patient with a medical history of treatment-resistant hypertension strongly suggest the diagnosis of primary aldosteronism. As the family history was negative for primary aldosteronism in this case, sporadic forms, i. e. idiopathic unilateral or bilateral adrenal hyperplasia and aldosterone-producing adenomas (Conn syndrome), which is the more severe variant of primary aldosteronism, have to be considered. For biochemical confirmation of the clinical suspicion of primary aldosteronism, the aldosterone to renin ratio (ARR) would have to be determined.

Hypokalemic paralysis due to primary aldosteronism, most likely Conn syndrome.

This very low serum potassium level led to the diagnosis of hypokalemic paralysis. Generally, hypokalemia can result from increased renal or gastrointestinal loss or increased cellular uptake (Table 1). Hypokalemia is often associated with QT prolongation and the risk of ventricular tachycardia (particularly torsades de pointes), which can be further aggravated by the administration of drugs known to prolong the QT interval [11]. Hypokalemia in patients with hypertension should initiate a search for primary hyperaldosteronism. After discontinuation of diuretics screening is performed by measuring the plasma levels of aldosterone and renin to calculate the ARR (Table 2). This patient’s ARR was significantly increased (20.4, normal: <12), indicating primary aldosteronism. As the ARR is only a screening tool, the definite diagnosis of primary aldosteronism has to be confirmed by additional diagnostic tests including suppression tests with saline, fludrocortisone and captopril and the oral salt loading test. In the first three tests, post-suppression serum aldosterone concentration is used as a diagnostic criterion; the oral salt loading test assesses 24-h urinary aldosterone excretion [7]. With the saline suppression test, we found a post-suppression plasma aldosterone concentration of 55 ng/dl (cut-off value for aldosterone: >10 ng/dl), which clearly confirmed primary aldosteronism in our patient.

Hypersecretion in primary aldosteronism is often caused by a single aldosterone-producing adenoma in one adrenal gland: MRI revealed a unilateral adenoma, 2 cm in diameter in the left adrenal gland. This prompted the diagnosis of classical solitary Conn adenoma.

Bilateral selective adrenal venous sampling (AVS, i.e. the selective blood sampling from adrenal veins and a peripheral site via a percutaneous femoral vein approach and the comparison of the cortisol-corrected aldosterone secretion between the two sides using the lateralization index) is the gold standard procedure for differentiating unilateral (surgically curable) and bilateral adrenal disease [12]. The AVS is a challenging procedure (particularly the cannulation of the right adrenal vein) and the success rate greatly depends on the expertise of the angiographer. In many centers the right adrenal vein is successfully cannulated in 50–80 % of cases [13, 14]. Only a few centers report success rates >95 % [15]. Unlike the left adrenal vein, which can be easily identified by its drainage into the superior aspect of the left renal vein, the right adrenal vein drains directly into the inferior vena cava in the neighborhood of a number of small vessels (e.g. accessory hepatic, phrenic and retroperitoneal veins) that may look like the right adrenal vein [16]. Moreover, the right adrenal vein is small and short, so that catheters can easily become dislodged during blood collection. In our patient AVS clearly suggested a left unilateral adenoma as indicated by MRI. Within 3 weeks after minimally invasive left-sided adrenalectomy the patient’s blood pressure decreased from 180/100 mmHg to 120/80 mmHg and serum potassium levels returned to normal. In 30–40 % of patients with Conn syndrome adrenalectomy results in permanent normalization of the blood pressure without further need of medication, as was also the case with our patient.

The symptoms in hypokalemic paralysis can last from minutes to hours or several days. Some individuals have only one episode in their lifetime but more commonly, crises occur repeatedly: daily, weekly, monthly or even less often. Events that are associated with an increased release of epinephrine or insulin can precipitate hypokalemic paralysis as they cause increased movement of potassium into cells and a subsequent decrease in serum potassium [18, 19]. Major triggering factors are either rest after strenuous physical activity, stress or a high carbohydrate load. From my personal experience I remember two cases of hypokalemic paralysis that were both associated with these typical triggering factors. The first patient was a student on a summer internship involving heavy manual labor; his daily diet was very high in carbohydrates including up to 3 l of sugar-sweetened beverages. This constellation finally led to hypokalemic periodic paralysis. The second case was a bride who presented with hypokalemic paralysis on her wedding day. Again, stress, physical activity (in this case dancing) and a high-carbohydrate meal were the triggering factors. It is of interest that our patient developed paralysis on Easter Sunday, when people typically have a large festive meal.

When hypokalemic periodic paralysis is suspected, the diagnosis has to be confirmed by electrophysiology, provocation tests and/or genetic analysis. Detailed information on this testing is available elsewhere [20]. The exercise test determines muscle strength by electromyography after nerve stimulation. The characteristic changes are important findings for defining the cause of paralysis, i.e. which ion channel is affected. Alternatively, a glucose provocation test, which aims to decrease serum potassium levels to below 3 mmol/l by oral administration of 2 g glucose/kg body weight and 10–20 IU insulin subcutaneously or i.v. administration of 1.5–3 g glucose/kg body weight and insulin over a period of 60 min, can confirm the diagnosis of hypokalemic periodic paralysis. In hypokalemic paralysis, serum concentrations of potassium are typically low (0.9–2.5 mmol/l) during attacks but not in between. Moreover, a positive family history is consistent with autosomal dominant inheritance. Of all individuals meeting the diagnostic criteria for hypokalemic periodic paralysis, approximately 60 % have mutations in the calcium channel CACNA1S gene, 20 % in the sodium channel SCN4A gene and 3.5 % in the potassium KCNJ18 gene [17]. Depending on the mutation, paralysis in the affected patients may be due to hyperkalemia or hypokalemia (Table 3). It is important to know that in patients with hypokalemic periodic paralysis, CK levels may be increased even without myotonia, as in our patient.

Mutations in the potassium channel KCNJ2 gene (inward-rectifier potassium ion channel) often presents clinically as Andersen-Tawil syndrome; however, penetrance is extremely variable, with some carriers of the mutation displaying little or no phenotypic expression [21]. This rare syndrome is characterized by a triad of episodic flaccid muscle weakness (periodic paralysis), ventricular arrhythmia with prolonged QT interval and skeletal anomalies [22]. Neurological presentation commonly includes episodic weakness of skeletal muscles in a generalized pattern with sparing of bulbar and respiratory musculature and reflexes may be absent or diminished during the episodes of weakness. Electrophysiological evaluation of the nerves is of great diagnostic value, as abnormalities are seen with sensitive testing in about 80 % of cases. Classical electrocardiographic abnormalities include prominent Q waves, prolonged QT and QU intervals, ventricular arrhythmias, such as premature ventricular contractions, polymorphic ventricular tachycardia and bidirectional ventricular tachycardia. Skeletal anomalies in the syndrome are micrognathia, retrognathia, clinodactyly, syndactyly, low-set ears and hypertelorism [23].

Table 4 provides an overview of hypokalemic and hyperkalemic causes of paralysis, corresponding characteristic symptoms, affected ion channels and treatment options.

For biochemical screening for primary aldosteronism in at-risk populations, there are no internationally accepted standardized assays that are calibrated against a standard reference substance. Calculation of the ARR is, however, a widely accepted approach [24]. The ratio has superior test characteristics to either plasma aldosterone concentration or plasma renin concentration (or activity) alone [25] and it shows less intra-day and inter-day variation. It is also less influenced by preanalytical variables, such as salt intake, diuretic exposure and posture prior to collection [26].

Calculated ARRs from different laboratories are, however, hardly comparable because the results are significantly influenced by (1) the assays used to determine aldosterone and renin and (2) the prevailing preconditions for blood sampling. The ARR can be calculated from both the direct “active” renin concentration (aldosterone to direct active renin concentration ratio, AARR) and the plasma renin activity (aldosterone to renin activity ratio, ARAR). It is important to know that both parameters are different metrics of the renin-angiotensin-aldosterone system and will therefore show different positive screening rates [27]. As direct active renin concentrations are biased by various factors [7], some experts tend to use plasma renin activity rather than renin concentration to calculate the ARR [28, 29], even though screening using the renin concentration can also be effective [30]. The diagnostic accuracy of the ARAR is, however, limited by conditions that affect both renin concentrations (e.g. negative feedback inhibition by angiotensin II) and angiotensinogen concentrations (increased during pregnancy, glucocorticoid excess and estrogen administration; decreased in liver disease) [31]. In contrast, the advantages of ARAR over AARR may be a better low-end precision and a more complete assessment of the renin-angiotensin-aldosterone system tone [7]. Glinicki et al. recently suggested a similar diagnostic accuracy of the ARAR and AARR [32]. In summary, for practical and economic reasons ARAR can be replaced by the aldosterone to direct active renin concentration ratio (AARR). Due to these analytical complexities, the ARR should always be interpreted in the context of the full clinical picture including medical and family history of early cardiovascular events, of early onset of arterial hypertension, severity of hypertension, resistance to antihypertensive drugs, presence of adrenal adenoma, absolute aldosterone concentration, the presence of electrolyte abnormalities and responsiveness to aldosterone antagonists [7]. When screening is positive, a confirmatory aldosterone suppression test must be performed to definitely diagnose primary aldosteronism.

The prevalence of hypertension has increased over the past decades and currently affects about 1 billion people worldwide [34]. Although most cases of hypertension are “essential” or “idiopathic,” some cases have an identifiable cause, representing secondary hypertension for which curative therapy can be offered. The most common form of secondary hypertension is primary aldosteronism [5]. Primary aldosteronism was first described in 1955 by Conn at Yale University, who reported a 34-year-old woman with hypertension, intermittent paralysis, hypokalemia and metabolic alkalosis [35]. The patient further showed increased activity of urinary salt-retaining corticoid and was cured by removal of a benign adrenal adenoma [36]. Initially Conn suggested that about 20 % of hypertensive patients might be affected by primary aldosteronism but later revised his estimate to 10 % [37]. Currently it is suggested that in 5–13 % of patients with hypertension the cause is primary aldosteronism with higher rates in younger hypertensive patients [5, 7]. Dr. Pilz is an endocrinologist and will present some important facts on primary aldosteronism and tell us about experiences with this disease at the University Medical Center of Graz.

According to the Endocrine Society clinical practice guidelines, testing for primary aldosteronism should be considered in any of the following circumstances: (1) sustained blood pressure above 150/100 mmHg on each of three measurements obtained on different days, (2) hypertension (blood pressure >140/90 mmHg) resistant to three conventional antihypertensive drugs (including a diuretic), (3) controlled blood pressure (<140/90 mmHg) on four or more antihypertensive drugs, (4) arterial hypertension and spontaneous or diuretic-induced hypokalemia, (5) hypertension and adrenal incidentaloma, (6) hypertension and sleep apnea, (7) hypertension and a family history of early onset hypertension or cerebrovascular accident at a young age (<40 years) and (8) all hypertensive first-degree relatives of patients with primary aldosteronism [12]. As already described by Drs. Schiller and Raggam, primary aldosteronism is usually diagnosed by measuring plasma aldosterone and direct active renin concentrations or renin activity and calculating the ARAR or AARR. If ARAR or AARR is elevated, confirmatory aldosterone suppression should usually be conducted to verify autonomous aldosterone production and thus confirm the diagnosis of primary aldosteronism. When testing for primary aldosteronism it is recommended to withdraw mineralocorticoid receptor antagonists (e.g. spironolactone and eplerenone) and amiloride and triamterene for at least 4 weeks before blood sampling to avoid spurious results. Potassium should also be normalized before testing because hypokalemia strongly suppresses aldosterone secretion. If a young patient (<35 years) has marked aldosterone excess and spontaneous hypokalemia along with plasma renin levels below detection levels there may be no need for further confirmation testing [5]. Beyond these diagnostic procedures for primary aldosteronism, it should be emphasized that one important differential diagnosis for patients with profound hypokalemia and hypertension is ectopic, i.e. adrenocorticotropic hormone dependent Cushing syndrome that is usually accompanied by significant metabolic alkalosis and very rapid disease progression requiring early diagnosis and treatment [46]. Some drugs such as beta-adrenergic blockers, angiotensin-converting enzyme inhibitors or angiotensin receptor blockers may also impact on the ARR and it is desirable to withdraw these drugs for at least 4 weeks before testing.

In addition to renin (activity) and aldosterone levels for calculation of ARR or AARR, analysis of parathyroid hormone may be of additional diagnostic value in primary aldosteronism. Patients with significant primary aldosteronism frequently present with elevated parathyroid hormone levels that may be due to increased renal and fecal calcium loss, metabolic alkalosis or direct effects on the parathyroid glands mediated by aldosterone [47].

The overall prevalence of primary aldosteronism, which of course greatly depends on the diagnostic criteria applied (e.g. ARR cut-offs), is relatively low at our center; according to the Graz endocrine causes of hypertension (GECOH) study approximately 3–5 % of patients referred for screening for endocrine hypertension are diagnosed with primary aldosteronism per year at the University Medical Center in Graz [48, 49]. In absolute numbers this means 5 patients are diagnosed here per year; however, appropriate and targeted screening of suspicious patients is pivotal for early diagnosis and adequate therapy.

Hypokalemic paralysis due to primary aldosteronism (Conn syndrome).
